Project Description
DESCRIPTION
1. Fixed down light body, removable and changeable light source, No damage to ceilling;
2. LED Chip controled as ONE BIN ONLY
3. Traic, 0~10V and Dali dimming are available
ORDER CODE
| MODEL |
POWER (W) |
INPUT | LED | IP |
LUM FLUX |
|
ES007B |
7W | 110-240V AC | CITIZEN COB | 44 | 560 |
| ES007B |
10W |
110-240V AC | CITIZEN COB | 44 |
800 |
|
ES007B |
12W | 110-240V AC | CITIZEN COB | 44 |
960 |
COLOR AND BEAM OPTIONAL
| COLOR (ONE BIN ONLY) | 2700K/3000K/3500K/4000K/4500K/5000K/5700K/6500K |
| BEAM ANGLE | 24/38/60° |
* The CCT are measured with an accuracy of +100K
* The power consumption with tolerance +1W
* Luminous flux tolerance +10%
* Detailed product datasheet contact ECO LITE Sales
